Sanitary Butterfly Valve Stainless Steel Powder Butterfly Valve For Industrial

Brand Name : QiaoDa

Model Number : DN500

Certification : ISO

Place of Origin : China

MOQ : 1PC

Price : negotiated price

Payment Terms : T/T

Supply Ability : 100 units per month

Delivery Time : 15 word days

Packaging Details : Consultation with customers

Size : 1/2 inch - 48 inch

Temperature Range : -29°C to 538°C

End Connections : Flanged, Threaded, Butt Weld, Socket Weld

Leakage rate : 1% - 3%.

Pressure environment : Atmospheric pressure

Type : Butterfly valve

Applicable medium : Industrial flue gas

Nominal diameter : DN100-DN3000

Operation : Manual, electric or pneumatic

Material : Cast Iron, Ductile Iron, Carbon Steel, Stainless Steel, Bronze

Operating temperature : 100-500

Country of origin : China

Feature : Regulating flue gas

Contact Now

Sanitary Butterfly Valve Stainless Steel Powder Butterfly Valve Butterfly

1. Introduction

Butterfly valve is a simple structure of the regulating valve, but also can be used for low-pressure pipeline media switching control. Ventilation butterfly valve is a kind of non-closed type butterfly valve. Main products: large ventilation butterfly valve, electric ventilation butterfly valve, leakage rate of 0, explosion-proof ventilation butterfly valve.

2. Specification
The structure of the ventilation butterfly valve is welded using a centerline butterfly plate and a short structural steel plate, so it has no internal components such as connecting rods and bolts, and there will not be some component problems in the process of use, so the failure rate is very low. It is easy to use. It is a reliable valve device. And because its sealing system uses metal closure, although the sealing effect is not as good as the elastic seal, but the service life is longer than the elastic seal, and has the characteristics of high temperature resistance. So it has a wide range of applications in building materials, electric power, metallurgy and other industries. In the temperature is not higher than 300 degrees in the medium transportation pipeline, can realize the connection and shutdown regulation role. This kind of butterfly valve can also be specially customized according to the needs of customers, very humanized.

3. Parameter

Product name Ventilation butterfly valve Product brand QiaoDa
Product classification Flue valve Nominal pressure Atmospheric pressure
Product material Carbon steel or stainless steel Product size According to the drawing
Product caliber DN300-2000 Product weight According to the drawing
Model number diameter 0 D D. B L t d d Bolt hole number
(n)
(mm)
D04101 100 195 100 160 80 177 14 φ15 14 4
DD4102 150 250 150 215 238 17×17
D04103 200 305 200 270 270 16 8
D04104 250 365 260 330 90 300 12
D04105 300 430 310 385 180 342 18
DD4106 350 480 360 435 367
DD4107 400 535 410 490 392 20 18
D04108 450 585 460 540 417
DD4109 500 645 520 600 447
00410 600 745 620 700 497 16
D04111 700 850 710 800 260 570 22 32×32
DD4112 800 950 810 900 620 20
004113 900 1050 910 1000 670
D04114 1000 1150 1010 1100 720 22
DD4115 1100 1250 110 1200 300 790 24
DD4116 1200 1350 1210 1300 840
DD4117 1300 1450 1310 1400 890 24
28
DD4118 1400 1550 1410 1500 940

Sanitary Butterfly Valve Stainless Steel Powder Butterfly Valve For Industrial
